옵틱 클라우드의 Laser - ASE & SLD 제품들 입니다.


980nm Band ASE Broadband Light Source

6f20d81840ead.pngThe light source is based on spontaneous emission from rare-earth-doped fibers, offering good optical power and low polarization. It covers the 980nm wavelength range, making it suitable for testing fiber device losses, polarization, and for FBG grating production.





Product model


980nm Band ASE Broadband Light Source


ASE-980-2-SM-D
Operating wavelength 973~982nm, Output power 2 mW, Hi-1060, Desktop, FC/APC

Central wavelength: 980nm

Output power: 2mW



Parameter



Features

● Wide Spectrum Range

● High Stability

● Low Polarization Degree



Specifications


Optical Parameters

Unit

Typical Value

Remarks

Wavelength Range

nm

973~982

20dB range

Optical Power Spectrum Density

dBm/nm

≥-20


Output Isolation

dB

>35

Built-in isolator

Short-Term Stability (15 min)

dB

≤ ±0.02

Equivalent ≤ ±0.5%

Long-Term Stability (8 hrs)

dB

≤ ±0.05

Equivalent ≤ ±1.2%

Polarization Extinction Ratio (PER)

dB

≤ 0.2


Tail Fiber & Connector Type

-

Hi 1060

FC/APC

Electrical and Environmental Parameters

Desktop

Control method

Touchscreen/RS232 serial communication

Communication interface

DB9 Female

Power supply

100~240V AC,<30W

Dimensions

260(W)×280(D)×120(H)mm

Operating temperature range

-5~+35°C

Operating humidity range

0~70%


Spectrum





Application

● Fiber Laser

● Optical Grating Testing

● Optical Fiber Device Testing
