ATS9440 is a 4-channel, 14-bit, 125 MS/s waveform digitizer based on the 8-lane PCI Express interface.

Boasting data throughput as fast as 1.6 GB/s, ATS9440 is an ideal solution for many applications, including spectrometry, radar, ultrasonics, and RF signal recording.

Features:

• 125 MS/s Real Time Sampling per channel
• 1.6 GB/s throughput across PCIe x8 bus
• 4 Channels sampled at 14 bit resolution
• External clock from 125 MHz to 1 MHz
• Up to 65 MHz full power bandwidth
• ±100 mV to ±4 V Input Range
• 65 dB Signal to Noise Ratio
• NIST Traceable Calibration
• Continuous Streaming Mode
• Up to 2 Gigasamples of Dual-Port Memory
• Trigger Input & Auxiliary I/O connectors
• Half-Length PCIe x8 Card
• AlazarDSO Software allows quick start-up
• SDK for C++/C#, Python, MATLAB, and LabVIEW
• Support for Windows & Linux
